Solar Panel Connector To XT 60 Adapter
- Conductor: Class 5 (flexible) tinned coppe
- Insulation & Sheath Jacket:XLPE
- Rated voltage:TUV1500V
- Testing Voltage: 6500V,50Hz,10Min
- Working temperature:-40℃~+120℃
- Degree of protection: IP68
- Protection Class: Class Ⅱ
- Certification:IEC62852 /UL6703
Description
Solar extension cable featuring SAE adapters that convert to male and female MC4 connectors. This setup is incredibly versatile for various solar applications. The SAE connector comes with a handy dustproof and waterproof cap, ensuring that its internal components stay clean and dry, even in less – than – ideal conditions. The weatherproof wiring of the cable is engineered to endure both extreme heat and cold, making it a reliable choice. It’s compatible with most solar panel kits and is widely used in cars, motorbikes, as well as outdoor solar installations.
Specification
| Product Type | Solar connector to XT60 |
| Rated Voltage | 1500V |
| Test Volitage | 6KV(50Hz,1Min) |
| Rated Current | 35A,40A,45A |
| Contact Materials | Tin plated copper |
| Protection Degree | IP68 |
| Contact Resistance | ≤0.35mΩ |
| Insulation Material | PPO |
| Ambient Temperature | (‘)-40℃~120℃ |
| Cable Cross Section Area | 2.5/4/6mm² |
| Flame Class | UL94 V-0 |
| Standard | IEC62852/UL6703 |
